A+ Server 4124GS-TNR là một máy chủ 4U được thiết kế để hỗ trợ các ứng dụng tiên tiến.Máy chủ này hỗ trợ lên đến 8 GPU có chiều rộng gấp đôi với công nghệ kết nối trực tiếp, đảm bảo hiệu suất tối đa. Nó sử dụng 2 bộ vi xử lý AMD EPYC để đảm bảo xử lý không giới hạn
| Thông Số | Chi Tiết |
|---|---|
| CPU | Dual AMD EPYC™ 7003/7002 Series Processors (hỗ trợ AMD 3D V-Cache™ với BIOS v2.3 trở lên) Socket SP3, Hỗ trợ TDP lên đến 280W |
| Cores | Up to 128 Cores (64 per CPU) |
| Supported GPUs | 8 Double-Width/Single-Width PCI-E 3.0/4.0 x16 Card (Full Height Full Length) NVIDIA A100, V100, A40, T4, Quadro RTX, AMD Instinct Supports both active and passive cooled GPUs |
| CPU-GPU Interconnect | PCI-E Gen 4 x16 Direct Connect CPU-GPU Dual-Root |
| GPU-GPU Interconnect | NVIDIA NVLink Bridge (Optional), AMD Infinity Fabric (optional) |
| Memory Capacity | 32 DIMM slots, Up to 8TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM |
| Memory Type | 3200MHz ECC DDR4 RDIMM/LRDIMM |
| Chipset | System on Chip (SoC) |
| SATA | SATA3 (6Gbps) |
| Network Controllers | Provided via riser card |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 |
| Graphics | ASPEED AST2500 BMC |
| SATA/SAS | 24 SATA/SAS với controller |
| LAN | 2 RJ45 GbE LAN ports (rear), 1 RJ45 Dedicated IPMI LAN port |
| USB | 2 USB 3.0 ports (rear) |
| Video | 1 VGA Connector |
| COM Port | 1 COM port (header) |
| System BIOS | |
| BIOS Type | AMI 32Mb SPI Flash ROM |
| Management Software | IPMI 2.0, KVM với dedicated LAN, SSM, SPM, SUM, SuperDoctor® 5, Watchdog |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory. 4+1 Phase-switching voltage regulator |
| FAN | Fans với tachometer monitoring, Status monitor for speed control, Pulse Width Modulated (PWM) fan connectors |
| Temperature | Monitoring for CPU and chassis environment, Thermal Control for fan connectors |
| Form Factor | 4U Rackmountable |
| Model | CSE-418G2TS-R4016BP |
| Dimensions | Height: 7.0" (178mm), Width: 17.2" (437mm), Depth: 29" (737mm) |
| Package | 26.57" (H) x 27" (W) x 41" (D) |
| Weight | Net Weight: 65.5 lbs (29.7 kg), Gross Weight: 100 lbs (45.3 kg) |
| Available Colors | Black |
| Hot-swap | Up to 24x 2.5" SAS/SATA drive bays, 2x 2.5" SATA supported natively, 4x 2.5" NVMe (Gen3 only) supported natively |
| PCI-Express | 9 PCI-E 4.0 x16 (FHFL) slots hoặc 10 PCI-E 4.0 x16 (FHFL) slots mà không có NVMe devices |
| System Cooling | 8x 11.5K RPM heavy duty fans |
| Total Output Power | 2000W Redundant Power Supplies with PMBus |
| Power Supply Input | 1000W: 100 – 127Vac, 1800W: 200 – 220Vac, 1980W: 220 – 230Vac, 2000W: 230 – 240Vac, 2000W: 220 – 240Vac (UL only) |
| Power Supply Output | +12V Max: 83A / Min: 0A (100-127Vac), Max: 150A / Min: 0A (200-220Vac), Max: 165A / Min: 0A (220-230Vac), Max: 166A / Min: 0A (230-240Vac), Max: 166A / Min: 0A (220-240Vac) (UL only) |
| 12Vsb | Max: 3.5A / Min: 0A |
| Output Type | 25 Pairs Gold Finger Connector |
| Certification | Titanium Level 96% Titanium Level |
| RoHS | RoHS Compliant |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F), Non-operating Temperature: -40°C to 60°C (-40°F to 140°F), Operating Relative Humidity: 8% to 90% (non-condensing), Non-operating Relative Humidity: 5% to 95% (non-condensing) |
