Cable Impedance | 50 ohm ± 1 ohm |
Capacitance | 76.8 pF/m | 23.409 pF/ft |
DC Resistance, Inner Conductor | 5.151 ohms/km | 1.57 ohms/kft |
DC Resistance, Outer Conductor | 4.003 ohms/km | 1.22 ohms/kft |
DC Test Voltage | 2200 V |
Inductance | 0.194 μH/m | 0.059 μH/ft |
Insulation Resistance | 100000 MOhms-km |
Jacket Spark Test Voltage (rms) | 5000 V |
Operating Frequency Band | 1 - 15800 MHz |
Peak Power | 12.1 kW |
Velocity | 86% |
VSWR (typical) | 1.15 @ 806-960 MHz, 1.433 @ 1700-2000 MHz, 1.29 @ 4000-6000 MHz |
Return Loss (typical) | 23.13 dB @ 806-960 MHz, 14.99 dB @ 1700-2000 MHz, 18 dB @ 4000-6000 MHz |
