Thông số kỹ thuật | Chi tiết |
---|---|
Max Configurable Power (Watts) | 600 Watts / 1.0 kVA |
Output Voltage Distortion | Less than 5% |
Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz Sync to mains |
Other Output Voltages | 220V, 240V |
Topology | Line interactive |
Waveform Type | Sine wave |
Transfer Time | 6 ms typical, 10 ms maximum |
Input Frequency | 50/60 Hz +/- 3 Hz Auto-sensing |
Input Voltage Range for Main Operations | 170 - 300V Adjustable, 180 - 287V |
Other Input Voltages | 220V, 240V |
Battery Type | Lead-acid battery |
Typical Recharge Time | 3 hours |
Nominal Battery Voltage | 24 V |
Replacement Battery | APCRBC142 |
Expected Battery Life (Years) | 3 - 5 |
RBC Quantity | 1 |
Battery Charge Power (Watts) | 56 Watts |
Runtime | Dependent on load and configuration |
Efficiency Graph: | View Efficiency Graph |
Interface Port(s) | RJ-45 Serial, USB |
Control Panel | Multifunction LCD status and control console |
Surge Protection and Filtering | Surge energy rating: 455 Joules, multi-pole noise filtering, 0.3% IEEE surge let-through |
Surge Protection and Filtering Graph: | meets UL 1449 |
Maximum Height | 219 mm (21.9 cm) |
Maximum Width | 171 mm (17.1 cm) |
Maximum Depth | 439 mm (43.9 cm) |
Net Weight | 17.27 kg |
Shipping Weight | 19.55 kg |
Shipping Height | 376 mm (37.6 cm) |
Shipping Width | 595 mm (59.5 cm) |
Shipping Depth | 328 mm (32.8 cm) |
Color | Black |
Operating Temperature | 0 - 40°C (32 - 104°F) |
Operating Relative Humidity | 0 - 95% non-condensing |
Operating Elevation | 0 - 3048 meters (0 - 10,000 feet) |
Storage Temperature | -15 - 45°C (5 - 113°F) |
Storage Relative Humidity | 0 - 95% non-condensing |
Storage Elevation | 0 - 15,240 meters (0 - 50,000 feet) |
Audible Noise at 1 Meter from Surface | 41.0 dBA |
Online Thermal Dissipation | 100.0 BTU/hr |
