| Category | Specification |
|---|---|
| Output | |
| Max Configurable Power (Watts) | 800 Watts / 1.0kVA |
| Output Voltage Distortion | Less than 5% |
| Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz Sync to mains |
| Topology | Line interactive |
| Waveform Type | Sine wave |
| Input | |
| Input Frequency | 50/60 Hz +/- 3 Hz Auto-sensing |
| Input Voltage Range | 151 - 302V Adjustable, 160 - 286V |
| Number of Power Cords | 1 |
| Batteries & Runtime | |
| Battery Type | Lead-acid battery |
| Typical Recharge Time | 3 hours |
| Replacement Battery | APCRBC116 |
| Expected Battery Life | 3 - 5 years |
| RBC Quantity | 1 |
| Battery Charge Power | 99 Watts |
| DC Overcurrent Protection | 60A |
| Runtime | View Runtime Graph |
| Efficiency | View Efficiency Graph |
| Communications & Management | |
| Interface Port(s) | RJ-45 Serial, SmartSlot, USB |
| Control Panel | Multifunction LCD status and control console |
| Emergency Power Off (EPO) | Yes |
| Available SmartSlot™ Interface Qty | 1 |
| Surge Protection and Filtering | |
| Surge Energy Rating | 600 Joules |
| Filtering | Full-time multi-pole noise filtering: 5% IEEE surge let-through; zero clamping response time; meets UL 1449 |
| Physical | |
| Maximum Height | 89 mm (8.9 cm) |
| Maximum Width | 432 mm (43.2 cm) |
| Maximum Depth | 490 mm (49.0 cm) |
| Net Weight | 22.86 kg |
| Shipping Weight | 27.32 kg |
| Shipping Height | 246 mm (24.6 cm) |
| Shipping Width | 620 mm (62.0 cm) |
| Shipping Depth | 589 mm (58.9 cm) |
| Color | Black |
| Environmental | |
| Operating Temperature | 0 - 45°C |
| Operating Relative Humidity | 0 - 95% |
| Operating Elevation | 0 - 3048 meters |
| Storage Temperature | -15 - 45°C |
| Storage Relative Humidity | 0 - 95% |
| Storage Elevation | 0 - 15240 meters |
| Audible Noise | 40.0 dBA at 1 meter from surface of unit |
| Online Thermal Dissipation | 82.0 BTU/hr |
| Conformance | |
| Approvals | CE, EAC, RCM, VDE |
