| Category | Specification |
|---|---|
| Output | |
| Max Configurable Power (Watts) | 12.0kWatts / 15.0kVA |
| Output Voltage Note | Configurable for 380 : 400 or 415 V 3 Phase nominal output voltage |
| Output Voltage Distortion | Less than 5% |
| Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz Sync to mains |
| Other Output Voltages | 220 V, 240 V |
| Load Crest Factor | 3 : 1 |
| Topology | Double conversion online |
| Waveform Type | Sine wave |
| Overload Operation | 60 seconds at 125% and 30 seconds at 150% |
| Bypass | Built-in static bypass, Internal bypass (automatic and manual), Optional external bypass |
| Input | |
| Input Frequency | 40 - 70 Hz Auto-sensing |
| Input Voltage Range for Main Operations | 160 - 280V |
| Input Total Harmonic Distortion | Less than 5% for full load |
| Other Input Voltages | 220 V, 240 V |
| Input Power Factor at Full Load | 0.95 |
| Batteries & Runtime | |
| Battery Type | Lead-acid battery |
| Included Battery Modules | 4 |
| Typical Recharge Time | 2.5 hours |
| Nominal Battery Voltage | +/- 192 V (split battery referenced to neutral) |
| Replacement Battery | APCRBC140 |
| Expected Battery Life | 3 - 5 years |
| RBC Quantity | 4 |
| Battery Charge Power | 1.53kWatts |
| Extendable Run Time | Yes |
| Efficiency in Battery Operation | 93.0% |
| Runtime | View Runtime Graph |
| Efficiency | View Efficiency Graph |
| Communications & Management | |
| Interface Port(s) | DB-9 RS-232, RJ-45 10/100 Base-T, Smart-Slot |
| Pre-Installed SmartSlot™ Cards | AP9631 |
| Emergency Power Off (EPO) | Yes |
| Surge Protection and Filtering | |
| Filtering | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Physical | |
| Maximum Height | 533MM, 53.3CM |
| Maximum Width | 432MM, 43.2CM |
| Maximum Depth | 773MM, 77.3CM |
| Net Weight | 247.73KG |
| Shipping Weight | 314.09KG |
| Shipping Height | 990MM, 99.0CM |
| Shipping Width | 610MM, 61.0CM |
| Shipping Depth | 1003MM, 100.3CM |
| Color | Black |
| Master Carton Dimensions (Length x Width x Height) | 1200 x 1000 x 1120MM |
| Master Carton Units | 2.0 |
| Master Carton Weight | 626.86KG |
| Environmental | |
| Operating Temperature | 0 - 40 °C |
| Operating Relative Humidity | 0 - 95% (Non-condensing) |
| Operating Elevation | 0 - 3048 meters |
| Storage Temperature | -15 - 45 °C |
| Storage Relative Humidity | 0 - 95% (Non-condensing) |
| Storage Elevation | 0 - 15240 meters |
| Audible Noise | 50.0 dBA at 1 meter from surface of unit |
| Online Thermal Dissipation | 2800.0 BTU/hr |
| Protection Class | IP20 |
| Conformance | |
| Approvals | VDE |
