Category | Specification |
---|---|
Output | |
Max Configurable Power (Watts) | 700 Watts / 1.0kVA |
Output Voltage Note | Configurable for 220 : 230 or 240 nominal output voltage |
Output Voltage Distortion | Less than 3% |
Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz Sync to mains |
Other Output Voltages | 220 V, 240 V |
Load Crest Factor | 3 : 1 |
Topology | Double conversion online |
Waveform Type | Sine wave |
Bypass | Built-in bypass |
Input | |
Input Frequency | 50/60 Hz +/- 5 Hz Auto-sensing |
Input Voltage Range for Main Operations | 160 - 280V |
Number of Power Cords | 1 |
Other Input Voltages | 220 V, 240 V |
Batteries & Runtime | |
Battery Type | Lead-acid battery |
Included Battery Modules | 1 |
Typical Recharge Time | 3 hours |
Replacement Battery | RBC31 |
Expected Battery Life | 3 - 5 years |
RBC Quantity | 1 |
Battery Charge Power | 109 Watts |
Extendable Run Time | Yes |
Runtime | View Runtime Graph |
Efficiency | View Efficiency Graph |
Communications & Management | |
Interface Port(s) | DB-9 RS-232, SmartSlot |
Emergency Power Off (EPO) | Optional |
Available SmartSlot™ Interface Quantity | 1 |
Surge Protection and Filtering | |
Surge Energy Rating | 420 Joules |
Filtering | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Physical | |
Maximum Height | 432 MM, 43.2 CM |
Maximum Width | 85 MM, 8.5 CM |
Maximum Depth | 483 MM, 48.3 CM |
Net Weight | 23.0 KG |
Shipping Weight | 27.8 KG |
Shipping Height | 286 MM, 28.6 CM |
Shipping Width | 630 MM, 63.0 CM |
Shipping Depth | 594 MM, 59.4 CM |
Color | Black |
Master Carton Dimensions (Length x Width x Height) | 1200 x 1000 x 1350 MM |
Master Carton Units | 4.0 |
Master Carton Weight | 522.4 KG |
Environmental | |
Operating Temperature | 0 - 40 °C |
Operating Relative Humidity | 0 - 95% (Non-condensing) |
Operating Elevation | 0 - 3048 meters |
Storage Temperature | -20 - 50 °C |
Storage Relative Humidity | 0 - 95% (Non-condensing) |
Storage Elevation | 0 - 15240 meters |
Audible Noise | 50.0 dBA at 1 meter from surface of unit |
Online Thermal Dissipation | 324.0 BTU/hr |
Protection Class | IP20 |
Conformance | |
Approvals | C-Tick, CE, GOST, VDE |
