| Specification | Details |
|---|---|
| Output | |
| Max Configurable Power (Watts) | 500 Watts / 750VA |
| Output Voltage Note | Configurable for 220, 230, or 240 nominal output voltage |
| Output Voltage Distortion | Less than 5% |
| Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz Sync to mains |
| Other Output Voltages | 220 V, 240 V |
| Topology | Line interactive |
| Waveform Type | Sine wave |
| Transfer Time | 6 ms typical : 10 ms maximum |
| Input | |
| Input Frequency | 50/60 Hz +/- 3 Hz Auto-sensing |
| Input Voltage Range | 151 - 302 Adjustable, 160 - 286V |
| Number of Power Cords | 1 |
| Other Input Voltages | 220 V, 240 V |
| Batteries & Runtime | |
| Battery Type | Lead-acid battery |
| Typical Recharge Time | 3 hours |
| Replacement Battery | APCRBC123 |
| Expected Battery Life (years) | 4 - 6 |
| RBC Quantity | 1 |
| Battery Charge Power (Watts) | 56 Watts |
| Runtime | View Runtime Graph |
| Efficiency | |
| Efficiency Graph | View Efficiency Graph |
| Communications & Management | |
| Interface Port(s) | RJ-45 Serial, SmartSlot, USB |
| Control Panel | Multifunction LCD status and control console |
| Emergency Power Off (EPO) | Optional |
| Available SmartSlot™ Interface Quantity | 1 |
| Surge Protection and Filtering | |
| Surge Energy Rating | 459 Joules |
| Filtering | Full-time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Physical | |
| Maximum Height | 86MM, 8.6CM |
| Maximum Width | 432MM, 43.2CM |
| Maximum Depth | 409MM, 40.9CM |
| Net Weight | 16.6KG |
| Shipping Weight | 21.23KG |
| Shipping Height | 241MM, 24.1CM |
| Shipping Width | 584MM, 58.4CM |
| Shipping Depth | 546MM, 54.6CM |
| Color | Black |
| Environmental | |
| Operating Temperature | 0 - 40 °C |
| Operating Relative Humidity | 0 - 95 % |
| Operating Elevation | 0 - 3048 meters |
| Storage Temperature | -15 - 45 °C |
| Storage Relative Humidity | 0 - 95 % |
| Storage Elevation | 0 - 15240 meters |
| Audible Noise at 1 Meter from the Surface of the Unit | 42.0dBA |
| Online Thermal Dissipation | 46.0BTU/hr |
| Conformance | |
| Approvals | CE, EAC, RCM, TÜV, UK PSTI, VDE |
