Category | Specification |
---|---|
Output | |
Max Configurable Power (Watts) | 1.98kWatts / 2.2kVA |
Output Voltage Note | Configurable for 220V, 230V, or 240V nominal output voltage |
Output Voltage Distortion | Less than 5% |
Output Frequency (sync to mains) | 50/60 Hz +/- 3 Hz Sync to mains |
Other Output Voltages | 220V, 240V |
Topology | Line interactive |
Waveform Type | Sine wave |
Transfer Time | 6 ms typical / 10 ms maximum |
Input | |
Input Frequency | 50/60 Hz +/- 3 Hz Auto-sensing |
Input Voltage Range | 151 - 302V Adjustable, 160 - 286V |
Number of Power Cords | 1 |
Other Input Voltages | 220V, 240V |
Batteries & Runtime | |
Battery Type | Lead-acid battery |
Typical Recharge Time | 3 hours |
Replacement Battery | RBC43 |
Expected Battery Life | 3 - 5 years |
RBC Quantity | 1 |
Battery Charge Power | 169 Watts |
Runtime | View Runtime Graph |
Efficiency | View Efficiency Graph |
Communications & Management | |
Interface Port(s) | RJ-45 Serial, SmartSlot, USB |
Control Panel | Multifunction LCD status and control console |
Available SmartSlot™ Interface Qty | 1 |
Surge Protection and Filtering | |
Surge Energy Rating | 375 Joules |
Physical | |
Maximum Height | 86 mm (8.6 cm) |
Maximum Width | 432 mm (43.2 cm) |
Maximum Depth | 683 mm (68.3 cm) |
Net Weight | 42.31 kg |
Shipping Weight | 49.73 kg |
Shipping Height | 254 mm (25.4 cm) |
Shipping Width | 980 mm (98.0 cm) |
Shipping Depth | 600 mm (60.0 cm) |
Environmental | |
Operating Temperature | 0 - 40°C |
Operating Relative Humidity | 0 - 95% |
Operating Elevation | 0 - 3048 meters |
Storage Temperature | -15 - 45°C |
Storage Relative Humidity | 0 - 95% |
Storage Elevation | 0 - 15240 meters |
Audible Noise | 55.0 dBA at 1 meter from surface of unit |
Online Thermal Dissipation | 215.0 BTU/hr |
Conformance | |
Approvals | CE, EAC, GS Mark, IRAM, RCM, VDE |
