Technical Specifications:
Category | Specification |
---|---|
Output | |
Max Configurable Power (Watts) | 2.1 kWatts / 3.0 kVA |
Output Voltage Distortion | Less than 5% at full load |
Output Frequency (sync to mains) | 50 Hz Sync to mains |
Topology | Line interactive |
Waveform Type | Sine wave |
Transfer Time | 8 ms typical, 10 ms maximum |
Input | |
Input Frequency | 47 - 63 Hz |
Input Voltage Range for Main Operations | 170 - 300V Adjustable, 180 - 287V |
Other Input Voltages | 220V, 240V |
Number of Power Cords | 1 |
Batteries & Runtime | |
Battery Type | Lead-acid battery |
Typical Recharge Time | 3 hours |
Replacement Battery | APCRBC150 |
Expected Battery Life (years) | 3 - 5 |
RBC Quantity | 1 |
Battery Charge Power (Watts) | 183 Watts |
Runtime | View Runtime Graph |
Communications & Management | |
Interface Port(s) | USB |
Control Panel | Multifunction LCD status and control console |
Surge Protection and Filtering | |
Surge Energy Rating | 300 Joules |
Filtering | Full time multi-pole noise filtering, 0.3% IEEE surge let-through, zero clamping response time, meets UL 1449 |
Physical | |
Maximum Height | 435 mm (43.5 cm) |
Maximum Width | 197 mm (19.7 cm) |
Maximum Depth | 544 mm (54.4 cm) |
Net Weight | 43.0 kg |
Shipping Weight | 51.0 kg |
Shipping Height | 762 mm (76.2 cm) |
Shipping Width | 699 mm (69.9 cm) |
Shipping Depth | 381 mm (38.1 cm) |
Color | Black |
Environmental | |
Operating Temperature | 0 - 40 °C |
Operating Relative Humidity | 0 - 95 % |
Operating Elevation | 0 - 3048 meters |
Storage Temperature | -15 - 45 °C |
Storage Relative Humidity | 0 - 95 % |
Storage Elevation | 0 - 15240 meters |
Audible Noise at 1 Meter | 45.0 dBA |
Online Thermal Dissipation | 135.0 BTU/hr |
Conformance | |
Approvals | C-Tick, CE, EAC, GOST, SABS, UK PSTI, VDE |
