Polarization | Dual Slant (45 Degrees) |
Standards | WCS, AISG |
Frequency | 698 MHz to 2.36 GHz |
Gain | 13.1 to 15.4 dBi |
Power | 300 to 500 W |
Vertical BW | 4.3 to 12.9 Degree |
Horizontal BW | 80 to 93 Degree |
Front to Back Ratio | 26 to 35 dB |
Industry | Wireless Infrastructure |
Downtilt | 0 to 10 Degree |
MIMO | Yes |
Indoor/Outdoor | Outdoor |
VSWR | 1.50:1 |
Isolation | 25 dB |
Mounting | Pole Mount |
Impedance | 50 Ohms |
Connectors | 7/16 DIN, 7/16 DIN - Female |
Multi Band | Yes |
Multi Port | Yes |
Dimension | 1836 X 366 X 185 mm |
PIM | -150 dBc |
Weight | 21.3 kg |
RoHS | Yes |
